Overall Dimensions (L × W × H): 62.6" × 49.8" × 58.1" (159 cm × 129 cm × 148 cm)
Machine Net Weight: 725.5 lb (329 kg)
Frame Construction: Imported premium 80×50×3mm thick steel tubing with high-precision welding. The heavy-duty solid frame delivers strong visual texture and structural stability.
Cushion System: One-piece molded polyurethane seat pad with balanced firmness to stabilize movement path and ensure long-term comfort. Seat, backrest and roller pads are filled with high-density PU foam, covered with 1.2mm premium synthetic leather, with customizable color options available.
Pneumatic Seat Adjustment: Gas-spring adjustment system enables fast, effortless and highly safe position tuning.
Ratchet Adjustment Mechanism: Integrated ratchet system allows incremental starting position adjustment in 10° steps for personalized range of motion.
Knee Pad & Dual Footrest Design: Combined knee cushion and dual foot platforms provide full leg support and reduce shear torque stress on knee joints during exercise.
Raised Weight Stack Tower: Elevated weight stack allows users to adjust resistance directly from the seated position without standing up.
Premium Manufacturing Technology: Production adopts laser cutting, automatic robotic welding, CNC precision machining and other top-tier international equipment to meet high-end industrial production standards.
Double-Layer Anti-Corrosion Coating Process: Full sandblasting rust removal, immersion pre-treatment and full-surface phosphating film for base protection. Double electrostatic powder coating is applied: one anti-rust glaze primer plus decorative top coat to maintain long-lasting appearance and outstanding corrosion resistance.
Guide Rod & Cable: Φ20mm solid steel guide rod with polished anti-corrosion coating ensures ultra-smooth silent sliding and rust resistance. Self-lubricating Φ5.8mm steel cable features low friction loss and extended service life.
