Overall Dimensions (L × W × H): 79.9" × 77.6" × 80.1" (203 cm × 197 cm × 203 cm)
Machine Net Weight: 705.5 lb (320 kg)
Frame Construction: Imported premium 80×50×3mm thick steel tubing with high-precision welding. The heavy-duty solid frame delivers strong visual texture and structural stability.
Cushion System: One-piece molded polyurethane seat pad with balanced firmness to stabilize movement path and ensure long-term comfort. Seat, backrest and roller pads are filled with high-density PU foam, covered with 1.2mm premium synthetic leather, with customizable color options available.
Pneumatic Seat Adjustment: Gas-spring adjustment system enables fast, effortless and highly safe position tuning.
Independent Variable Cam Mechanism: Separate variable cam accurately simulates the natural torque curve of human movement for authentic biomechanical force feedback.
Ergonomic Multi-Function Arms: Scientifically engineered training arms fit users with all body heights and arm lengths. Dual-function design supports two distinct workouts: chest fly and rear delt fly.
5-Position Adjustable Starting Points & Iso-Lateral Design: Five selectable starting positions for chest fly accommodate different users’ range of motion requirements. Iso-lateral independent left-right arms enable unilateral & bilateral training to expand workout diversity.
Premium Manufacturing Technology: Production adopts laser cutting, automatic robotic welding, CNC precision machining and other top-tier international equipment to meet high-end industrial production standards.
Double-Layer Anti-Corrosion Coating Process: Full sandblasting rust removal, immersion pre-treatment and full-surface phosphating film for base protection. Double electrostatic powder coating is applied: one anti-rust glaze primer plus decorative top coat to maintain long-lasting appearance and outstanding corrosion resistance.
Guide Rod & Cable: Φ20mm solid steel guide rod with polished anti-corrosion coating ensures ultra-smooth silent sliding and rust resistance. Self-lubricating Φ5.8mm steel cable features low friction loss and extended service life.
